Newberry 2" Flip Top Fill Cap (SKU: FC2MFT)

Description

This 2-inch flip-top fill cap is a hinged, male-threaded aluminum cap for the fill point of an above-ground storage tank, used where a tight-fill dry-break connection is not required. It threads into a tank bung or onto a fill riser and swings open on a hinge for gravity or nozzle filling. A positive stop keeps the open cover from striking the tank shell, the cap is drilled for a padlock so the fill point can be secured, and it provides integrated venting when closed. Newberry supplies this cap as the Morrison Bros. FIG 179M.

Key Features

• Hinged operation: The cap stays attached to the fill point and swings open for filling.
• Positive stop: A built-in stop prevents the cover from contacting the tank when swung open.
• Lockable: Padlock-compatible design secures the fill opening against unauthorized access.
• Integrated venting: Provides integrated venting when the cap is closed.
• Aluminum body: Aluminum body and cap resist corrosion in outdoor above-ground service.
• Direct thread-in: Male NPT body threads straight into a 2 inch tank bung or fill riser.

Specifications

• Size: 2 in
• Thread: Male NPT
• Body material: Aluminum
• Cap material: Aluminum
• Hinge pin: Zinc-plated steel
• Weight: 0.75 lb
• Vented: Yes - integrated venting when closed
• Component manufacturer: Morrison Bros. Co.
• Component model: FIG 179M, part 179M-0100 AC
• Supplied by: Newberry Tanks
• Ships From: AR

Applications

• Fill point on UL-142 above-ground diesel, fuel oil and lube tanks filled by gravity or nozzle
• Farm, fleet and jobsite skid tanks that need a lockable fill opening
• Retrofit of an existing 2 inch tank bung or fill riser needing a secured, weather-resistant closure

Manufacturer Documents

• Morrison FIG 179 Specification Sheet

Shipping and Warranty

• Manufacture Lead Time: 3-5 Weeks
• Ships From (State): AR

Products are subject to freight or parcel shipping costs. Shipping charges are calculated at checkout based on delivery location, product size, weight, and carrier requirements.

Warranty Information
Warranty coverage on tank accessories is provided by the component manufacturer and varies by product. Newberry's one-year limited warranty is written to cover the tank itself. For warranty details or to start a claim, contact Tank Supply Direct at info@tanksupplydirect.com.
