NOMAD FKM (Viton®) Diaphragm for 1" Quali-Flo N1F Diaphragm Pumps (MPN N286-008-363)

Description

The NOMAD N286-008-363 is a FKM (Viton®) replacement diaphragm for 1" pumps (JDA Global: Diaphragm, Viton®), sold each. A pump uses 2, so order 2 to replace the full set. It fits the NOMAD pumps listed below, and it is the same part used in the NOMAD wet end kits listed below.

NOMAD parts are made by JDA Global of Henderson, Nevada. If you are replacing all the wetted elastomers at once, the matching wet end kit is usually the better value.

Key Features

• Diaphragm, Viton® — sold each
• Fits: Quali-Flo N1F
• Same part as in NOMAD kit: N476-194-633
• Ships from Henderson, NV in about 4 days

Compatible Pumps

• Quali-Flo N1F 1" Aluminum Buna-Fitted Diaphragm Pump, Bolted (N1FB1ABWANS000)
• Warren Rupp®: used in NOMAD kits for Warren Rupp® S1FM pumps (per JDA Global)

Included in These NOMAD Kits

• NOMAD N476-194-633 — 1" FKM/PTFE/PTFE Wet End Kit for Quali-Flo N1F Aluminum & Warren Rupp® S1FM Pumps

Specifications

• MPN: N286-008-363
• Part: Diaphragm, Viton®
• Quantity: 1 (each); 2 per pump
• Pump size: 1"
• Manufacturer: NOMAD (JDA Global)
• Ships from: Henderson, NV

Frequently Asked Questions

Is this sold as a pair?
No. The price is for one diaphragm. A pump uses 2.

Which pumps does the N286-008-363 fit?
Quali-Flo N1F 1" Aluminum Buna-Fitted Diaphragm Pump, Bolted (N1FB1ABWANS000).

Should I buy the kit instead?
If you are rebuilding the whole wet end, the kit N476-194-633 includes this part with the other wear parts.

How long does it take to ship, and where does it ship from?
About 4 days, shipping from Henderson, NV.

Shipping and Warranty

• Manufacture Lead Time: 4 Days
• Ships From (State): NV

Products are subject to freight or parcel shipping costs. Shipping charges are calculated at checkout based on delivery location, product size, weight, and carrier requirements.

Warranty Information
Warranty coverage varies by manufacturer and product type. For warranty details or to initiate a warranty claim, please contact Tank Supply Direct at info@tanksupplydirect.com.

Warren Rupp® is a registered trade name of IDEX Corporation. NOMAD® parts are not affiliated with these companies; names are used for identification purposes only.
