• Peabody Engineering CFL - Local Display, Backlight LCD Display, 4-20mA Output - Peabody catalog family photo (representative)

Peabody Engineering

Peabody Engineering CFL Float Level Sensor Transmitter with Local Backlit LCD Display, 4-20mA Output (6" to 72")

Peabody Engineering CFL Float Level Sensor Transmitter with Local Backlit LCD Display, 4-20mA Output (6" to 72")

SKU: 24-34418

3-5 Weeks
Price: $1,332.03
List Price:
Price: $1,332.03
Material
View Cart

Description

Peabody Engineering CFL float level sensor transmitter with a local backlit LCD display and 4-20mA output, for a 6" to 72" range, in PVC, PP, PVDF or 316 SS.

The CFL float level sensor transmitter uses a plastic float with a magnet inside. The float moves with the liquid level and excites a divider circuit inside the stem, which is converted into an analog 4-20mA output signal.

Key Features
  • Local Display: Backlit LCD display at the sensor
  • 4-20mA Output: Analog output signal
  • Four Materials: PVC, PP, PVDF or 316 SS
  • 6" to 72" Range: Float level measurement
Specifications
  • Range: 6" to 72"
  • Output: 4-20mA
  • Materials: PVC, PP, PVDF, 316 SS
  • Manufacturer Part Numbers: 24-34418 (PVC); 24-34419 (PP); 24-34420 (PVDF); 24-34421 (316 SS)
  • Manufacturer: Peabody Engineering
  • Ships From: Liberty, SC
Applications
  • Continuous tank level measurement with a local readout
Frequently Asked Questions

How does the CFL sensor work?
A magnetic float moves along the stem with the liquid level and the sensor converts its position into a 4-20mA signal.

Is there a version without a display?
Yes. Peabody also offers the CFL with a blind display and 4-20mA output.

How long does it take to ship, and where does it ship from?
It is built to order with a manufacture lead time of 3-5 weeks and ships from Liberty, South Carolina. Shipping is calculated at checkout.

Who makes it?
Peabody Engineering.
