Peabody Engineering Welded Couplings, Polypropylene, Natural Thread (1/2" to 4")

Description

Peabody Engineering welded couplings in polypropylene with natural threads, half and full couplings from 1/2" through 4". Each is available as the fitting only or installed in a new single wall tank; full couplings can also be installed in a double wall tank.

Choose the coupling size and type, then fitting only or installed.

Key Features

• Polypropylene: Natural thread coupling
• Half or Full Coupling: Both types in 1/2" to 4"
• Fitting Only or Installed: Peabody can weld it into a new single or double wall tank

Specifications

• Sizes: 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 3", 4"
• Types: Half coupling, full coupling
• Installation Options: Fitting only; installed in single wall tank; installed in double wall tank (full couplings)
• Manufacturer Part Numbers: 02-27302 (1/2" Half Coupling, installed single wall); 02-34182 (1/2" Half Coupling, fitting only); 02-27303 (3/4" Half Coupling, installed single wall); 02-34183 (3/4" Half Coupling, fitting only); 02-27304 (1" Half Coupling, installed single wall); 02-34184 (1" Half Coupling, fitting only); 02-27305 (1-1/4" Half Coupling, installed single wall); 02-34185 (1-1/4" Half Coupling, fitting only); 02-27306 (1-1/2" Half Coupling, installed single wall); 02-34186 (1-1/2" Half Coupling, fitting only); 02-27307 (2" Half Coupling, installed single wall); 02-34187 (2" Half Coupling, fitting only); 02-27308 (3" Half Coupling, installed single wall); 02-34188 (3" Half Coupling, fitting only); 02-27309 (4" Half Coupling, installed single wall); 02-34189 (4" Half Coupling, fitting only); 02-27310 (1/2" Full Coupling, installed single wall); 02-34166 (1/2" Full Coupling, installed double wall); 02-34174 (1/2" Full Coupling, fitting only); 02-27311 (3/4" Full Coupling, installed single wall); 02-34167 (3/4" Full Coupling, installed double wall); 02-34175 (3/4" Full Coupling, fitting only); 02-27312 (1" Full Coupling, installed single wall); 02-34168 (1" Full Coupling, installed double wall); 02-34176 (1" Full Coupling, fitting only); 02-27313 (1-1/4" Full Coupling, installed single wall); 02-34169 (1-1/4" Full Coupling, installed double wall); 02-34177 (1-1/4" Full Coupling, fitting only); 02-27314 (1-1/2" Full Coupling, installed single wall); 02-34170 (1-1/2" Full Coupling, installed double wall); 02-34178 (1-1/2" Full Coupling, fitting only); 02-27315 (2" Full Coupling, installed single wall); 02-34171 (2" Full Coupling, installed double wall); 02-34179 (2" Full Coupling, fitting only); 02-27316 (3" Full Coupling, installed single wall); 02-34172 (3" Full Coupling, installed double wall); 02-34180 (3" Full Coupling, fitting only); 02-27317 (4" Full Coupling, installed single wall); 02-34173 (4" Full Coupling, installed double wall); 02-34181 (4" Full Coupling, fitting only)
• Manufacturer: Peabody Engineering
• Ships From: Liberty, SC

Applications

• Threaded connections welded into polyethylene tanks

Frequently Asked Questions

What do the installation options mean?
Fitting Only is the coupling by itself. Installed in Single Wall Tank or Installed in Double Wall Tank means Peabody welds the coupling into a new tank of that type; order it together with the tank.

Can a half coupling go in a double wall tank?
Peabody lists the double wall installation for full couplings only.

How long does it take to ship, and where does it ship from?
It is built to order with a manufacture lead time of 3-5 weeks and ships from Liberty, South Carolina. Shipping is calculated at checkout.

Who makes it?
Peabody Engineering.

Manufacturer Documents

• Peabody catalog page: Welded Couplings

Shipping and Warranty

• Manufacture Lead Time: 3-5 Weeks
• Ships From (State): SC

Products are subject to freight or parcel shipping costs. Shipping charges are calculated at checkout based on delivery location, product size, weight, and carrier requirements.

Warranty Information
Peabody Engineering's published warranty is a full 3-year warranty on its standard tanks and a full 5-year warranty on its heavy-duty tanks, and it does not apply to special applications such as sodium hypochlorite and bio-diesel. Peabody does not state a separate warranty term for this item. For warranty details or to initiate a warranty claim, please contact Tank Supply Direct at info@tanksupplydirect.com. Source: Peabody Engineering FAQs
