NOMAD 1-1/2" PTFE Wet End Kit for Plastic Diaphragm Pumps, Fits Wilden® PS400/P400/PX400 & NOMAD NPF40 (MPN N04-9815-55)

Description

The NOMAD N04-9815-55 is a PTFE wet end elastomer kit for 1-1/2" plastic air-operated double diaphragm (AODD) pumps. It contains the 2 diaphragms, 2 back-ups, 4 balls and 8 O-rings/gaskets needed to rebuild the wetted side of one pump. It fits these NOMAD pumps sold by Tank Supply Direct: NPF40 (40-12611), and JDA Global lists it for Wilden® PS400, P400, PX400 plastic pumps.

NOMAD parts are made by JDA Global of Henderson, Nevada, as after-market replacements for NOMAD pumps and pumps from other manufacturers. The NOMAD part number follows the Wilden® numbering: N04-9815-55 corresponds to Wilden® kit 04-9815-55.

Key Features

• Complete wet end rebuild: 2 diaphragms, 2 back-ups, 4 balls, 8 O-rings/gaskets in one kit
• PTFE elastomers for 1-1/2" plastic pumps
• Matched to NOMAD NPF40: listed by JDA Global as the wet end kit for 40-12611
• Cross-references Wilden® 04-9815-55
• Ships from Henderson, NV in about 4 days

What's in the Kit

• 2 × Diaphragm, PTFE (N04-1010-55)
• 2 × Back-Up Diaphragm, Neoprene (N04-1060-51)
• 4 × Valve Ball, PTFE (N04-1080-55)
• 4 × T-Section O-Ring, Viton® Encapsulated PTFE, Poly, Clamped (N08-1300-60-500)
• 4 × Liquid Chamber O-Ring, Viton® Encapsulated, Poly, Bolted (N04-1371-60)

Compatible Pumps

• PWR-FLO NPF40 1-1/2" polypropylene PTFE-fitted, bolted (40-12611)
• Also fits these NOMAD model numbers (NPT / BSP): 40-125061-1, 40-12611
• Wilden®: PS400, P400, PX400 plastic pumps (per JDA Global)
• Replaces: Wilden® 04-9815-55

Specifications

• MPN: N04-9815-55
• Kit type: Wet end elastomer kit
• Pump size: 1-1/2" (38 mm)
• Pump construction: Plastic
• Elastomer: PTFE
• PTFE temperature range: 40°F to 220°F (4.4°C to 104.4°C)
• Neoprene temperature range: 0°F to 200°F (-17.8°C to 93.3°C)
• Kit weight: 3.02 lb (sum of component weights)
• Manufacturer: NOMAD (JDA Global)
• Ships from: Henderson, NV

Frequently Asked Questions

Which pumps does the N04-9815-55 kit fit?
The NOMAD NPF40 (40-12611) pumps, and Wilden® PS400, P400, PX400 plastic pumps.

What is included?
2 × Diaphragm, PTFE; 2 × Back-Up Diaphragm, Neoprene; 4 × Valve Ball, PTFE; 4 × T-Section O-Ring, Viton® Encapsulated PTFE, Poly, Clamped; 4 × Liquid Chamber O-Ring, Viton® Encapsulated, Poly, Bolted.

Is there a version with a different elastomer?
Yes. NOMAD N04-9815-52 is the Buna-N wet end kit for the same pumps.

Is this a genuine Wilden® part?
No. It is a NOMAD after-market part made by JDA Global. NOMAD is not affiliated with Wilden®; Wilden® names and part numbers are used for identification only.

How long does it take to ship, and where does it ship from?
About 4 days, shipping from Henderson, NV.
